How Does A Bird's Eye View Camera Work

Manoeuvring a vehicle with confidence can get tricky. Just think about all the things that can block your view: window pillars, seats, headrests and passengers all brand these potentially trying tasks even harder.

When determining the gap between you and another vehicle, while avoiding the adjourn, you would exist forgiven for wanting to get out of the auto to go a better wait. Thankfully you don't have to.

Toyota's Bird'south Eye View camera, available on the Camry, RAV4 and Highlander, not only provides drivers with a 360-degree view from higher up the car, just also a virtual view from within as if the vehicle was completely run into-through.

And so how does it work?

How the Bird'southward Eye View camera works

Four cameras are mounted on the outside of the vehicle; ane under each rearview mirror, i under the front grille and another mounted near the rear license plate. The camera positioning enables a complete view  around the vehicle. Each camera view is fed into a estimator, which stitches the images together – creating a true panoramic, seamless single prototype on screen.

How to apply the Bird's Heart View camera

The system engages automatically when the vehicle is put into reverse. Drivers can as well engage the system manually by pressing the Bird's Eye View Button. A clear view of your Toyota'due south surroundings appears on the central display screen, and various view modes can be selected:

• The "Bird's Eye View" which allows drivers to see the total way around the vehicle's perimeter, on a unmarried screen. It's like a backup camera that shows y'all what's behind, beside, and in front of you, simultaneously.

• A split-screen view that shows the Bird'southward Eye View and a conventional backup camera view side past side.

• A adjourn view fashion with a camera angle focused down the side of the vehicle. This view mode is particularly useful to assist prevent scraping the vehicle's wheels during parallel parking next to a curb, to help line up properly between parking lines, or for extra confidence when slowly passing oncoming traffic on narrow roads.

• The front view way, which enables a closer check for clearance when parking

Using Perimeter Scan

The Bird's Center View photographic camera besides features Perimeter Browse – two different 360-degree rotating views that use three-D graphics to evidence surrounding objects when your vehicle is in park, parking assist is activated, and the bird's eye view button is depressed.

First is the Perimeter Browse'southward Moving View which places a 3-D modelled Camry, RAV4 or Highlander in the heart of a wide-angle overhead image, which shows the precise placement of all objects most the vehicle, in real fourth dimension. The image rotates slowly on screen, allowing drivers to see their entire surroundings, all at one time. Imagine, watching a alive stream of a drone camera flying in a circumvolve above your Toyota, and you're in the right ballpark.

2nd, is the Perimeter Scan's Run into-Through View. In this mode, the system manipulates camera inputs to simulate a virtual view from the commuter's perspective as if the vehicle was transparent. The on-screen display rotates a full 360 degrees, showing drivers a footing-level image of their environment and taking the guess work out of avoiding nearby objects.

Both Perimeter Scan views let drivers to break the video feed, should they need a closer await at something they come across on screen. The various camera modes tin can be selected at the touch of a button—providing quick access to the best fashion for the current situation.

This smart functionality helps make manoeuvring your vehicle safer and more straightforward. No matter where you're going, the Bird's Eye View photographic camera system provides real added confidence.

Of form, the Bird'due south Heart View camera is just i of several handy drivers assist technologies offered by the hazard-prepare Toyota vehicles.

Cold conditions and other ecology factors may limit system. Operates at low speed or when parked. Do not rely exclusively on the organization equally it is not intended to replace safe circumspect operation of the vehicle. You should also look effectually exterior your vehicle, over your shoulder and use your mirrors to confirm clearance.

For more information on the Bird's Eye View camera, please run into your local Toyota Dealer or Possessor'south Transmission for details .  Detect Toyota Owner'south Manuals here.
